-30°C Forced Air Cooling Biomedical Freezer YR05308-1

Description

Description
The YR05308-1 Forced Air Cooling Biomedical Freezer is the ideal solution for storing critical biological samples, medical products, and laboratory materials that require controlled temperature conditions. This model, designed for blood banks, hospitals, disease control centers, and research laboratories, offers an adjustable temperature range of -10°C to -30°C, ensuring precise and reliable cooling. Its forced air cooling system provides efficient and uniform cooling, while the automatic defrost feature ensures the unit’s operation is not interrupted by ice buildup, optimizing performance.

Features
Model: YR05308-1
Cabinet Type: Upright
Climate Class: SN N
Cooling Type: Forced air cooling
Defrost Mode: Automatic defrost
Refrigerant: HC
Sound Level: 44 dB(A)
Cooling Performance: -30°C
Temperature Range: -10°C to -30°C
Controller: Microprocessor
Display: LED
Power Supply: 220-240 V/50 Hz
Power: 650 W
Electrical Current: 3.1 A
Capacity: 520 L/18.4 cu.ft
Net/Gross Weight: 210/252 kg
Interior Dimensions: 610*755*1006 mm
Exterior Dimensions: 848*1011*1780 mm

Technical Specifications
Model YR05308-1
Technical Data
Cabinet Type Upright
Climate Class SN N
Cooling Type Forced air cooling
Defrost Mode Automatic defrost
Refrigerant HC
Sound Level((dB(A))| 44
Performance
Cooling Performance (°C) -30
Temperature Range (°C) -10–30
Control
Controller Microprocessor
Display LED
Electrical Data
Power Supply(V/Hz) 220-240/50
Power(W) 650
Electrical Current(A) 3:1
Dimensions
Capacity(L/Cu.Ft) 520/18.4
Net/Gross Weight (approx) (kg) 210/252
Interior Dimension (W×D×H) (mm) 610*755*1006
Exterior Dimension (W×D×H) (mm) 848*1011*1780
Alarms
High/Low Temperature Y
Remote Alarm Y
Power Failure Y
Sensor Error Y
Low Battery Y
High Ambient Temperature Y
Door Ajar Y
Accessories
Castor Y
Foot Y
Porthole Y
Drawers/Inner Doors /
USB Interface Optional
RS485 Y
NFC Optional
Temperature Recorder Optional
