6 Channel Smart Hospital ECG Manufacturing Machine Monitoring Dynamic Holter ECG Systems YR05161

Description

Description
The 6 Channel Smart Hospital ECG Manufacturing Machine Monitoring Dynamic Holter ECG Systems YR05161 combines cutting-edge technology with ease of use, ensuring reliable and accurate measurements for cardiologists. This state-of-the-art equipment offers comprehensive data management options and a high diagnostic confidence, making it an essential tool for any healthcare facility looking to enhance patient care.

Features
Advanced 6-channel monitoring
Accurate measurements and interpretations
Multiple work modes: MAN, AUTO, ANALYSIS
Comprehensive data management
Protective features against defibrillator effects
7-inch high-definition LCD screen

Technical Specifications
Model YR05161
Guide 12 standard conductors
Input dynamic range ± 10Vpp
Patient current leak <10μA
Calibration Voltage 1mV ± 2%
Tension Tolerance ≥ ± 500mV
Time constant ≥3.2s
Frequency response 0.05 ~ 160Hz (-3db)
Noise level <15μVp-p
Input circuit current 0.050.05 μA
Sensitivity 2.5, 5.10, 20mm / mV
Interchannel interference ≤0.5mm
Paper speed 6.25,12.5, 25.50mm / s (± 3%)
Patient current leak <10μA
AC filter 50Hz / 60Hz
EMG filters 25Hz / 45Hz
Anti-drift filter 0.15 Hz (adaptive)
CMMR ≥120dB (with AC filter)
Sensitivity Valve ≤20μV
Input impedance ≥50MΩ
Work Modes MAN, AUTO, ANALYSIS modes
Acquisition of Potential Customers 12 bits / 1000 Hz (synchronously 12 leads)
Input Circuit floating; protection circuit against defibrillator effect
Screen 7 inch LCD
