Description
Feature
1. Exquisite workmanship:small design,0.2kg weight, more installation way optional
2. Multiple Temperature Control Protection Technology: Hardware and softwaretemperature control protection to ensure the effective and safe heating
3. 2 mins Fast Heating: Fast heating to transfer the heat to the patient
4. Three Heating Groove: Long, middle , short groove to meet different needs
5.High Accuracy: Deviation is within土1°℃
Specification
Temperature Setting
°C: 32℃~42.0°C;°F:95.0°F~107.6°F
Temperature Deviation
°C:≤±1℃
°F:≤±1.8°F
Temperature Increment
°C:0.1℃
°F:0.2F
Optional Unit
°C
°F
Warming up time
≤2min
Overheat Protection
46℃
hardware and software protection
Alarm
Overheat
low temperature
system error
over time
warming up alarm
Blood/Iv Sets
Standard single use PVC blood/IV tubes
( diameter: 3.4-4.5mm)
Display
LED
Heating Way
Long
Middle
short grooves
lnstallation Way
lV Knob
Hanger optional
Power Supply
Input:100-240V(AC Power)，
50/60HZ
0.3-0.7A
Output: 12v(DC Power)2.5A
Power Consumption
85VA
Operation Environment
Temp.:+5*C-+30″C; Relative Humidity: 20%-80% ;
Atmosphere:76.0kPa-106.0kPa
Transportation and Storage Environment
Temp:-20°℃-+55°C
Relative Humidity: 10%-93%
Atmosphere:50.0kPa-106.0kPa
Degree of Protection against Ingress of Liquids
IPX1
Degree of Protectionagainst Electric Shock
Class ll
Type CF
Working Mode
Continous heating
Dimension
180x70x35mm
Weight Net Weight
0.2kg ; With Knob:0.4kg
