Close Cup Flash Point Tester, Automatic Control

Description

Close Cup Flash Point Tester Features:
The close cup flash point tester adopts an 8-inch IPS high-definition capacitive screen.
Using 32-bit ARM processor and high-precision AD chip, the test data and parameters are recorded in real time and displayed by curve.
Equipped with Bluetooth interface. The user can query test data anytime.
Remote automatic upgrade to obtain the latest version, remote prediction, abnormal early warning, comprehensive evaluation and maintenance of instrument operation status.
Automatic measurement of atmospheric pressure, automatic correction of flash point value.
Temperature rise, cover opening, ignition, detection and printing data are completed automatically, and the test arm rises and falls automatically.
Electronic ignition, gas flame, automatic air cooling at the end of the test

Close Cup Flash Point Tester Specifications:
Model FPT-261D
Flash Point Determination Range: Ambient to 230℃
Accuracy: 0.1℃
Heating Rate Procedure A: (5～6)℃/min
Procedure B: (1～1.5)℃/min
Procedure C: (3.0±0.5)℃/min
Stirring Rate Procedure A and C: (90～120)RPM
Procedure B: (250±10)RPM
Automatic control and manually adjustable
Igniting Mode 1. Electric ignition
2. Diameter of igniter : 0.7mm～0.8mm
Data Transmission Mode Bluetooth
Suitable Temperature Ambient temperature : (15～35)℃
Relative humidity ≤85%
Power Supply AC(220±5%)V, 50Hz
Total Power Consumption ≤600W
Size(W×D×H)(mm) 510x320x330
Net Weight 20kg
Package Size(W×D×H)(mm) 690x520x610
Gross Weight 35kg
