Digital Microscope, Infinite Optical System

Description

Digital Microscope Specifications:
Model MSC-D201
Optical System Infinite Optical System
Viewing Head 10-inch display screen
Video Adapter C Mount 0.5×/1×
Objective Infinite Plan Achromatic Objective: 4×, 10×, 20×, 40×, 100×
Nosepiece Quadruple Nosepiece/xQuintuple Nosepiece
Stage Double Layers Mechanical Stage 140X135mm, Range of Movement: 75X50mm
Condense Abbe Condenser N.A. 1.25 with Iris Diaphragm & Filter
Focusing System Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Coarse
Stroke 37.7mm per Rotation,
Fine Stroke 0.2mm per Rotation, Moving Range 20mm
Illumination 3W LED Light, Brightness Continuously Adjustable
Optional Turret Phase Contrast Kit; Dark Field Attachment; Fluorescent Attachment
Microscope Camera/win10 Pad/Digital Display
Shipping Size
(W×D×H)(mm) 370x260x470
G.W. (kg) 8

Digital Microscope Specifications:
The digital microscope has an advanced infinite optics system that provides superior optical clarity for precise observation and analysis.
The 10-inch display provides a user-friendly and immersive visual experience.
The integrated display eliminates the need for traditional eyepieces, improves comfort and promotes group observation.
Microscope seamlessly connects to various imaging devices, such as cameras and digital displays, for efficient documentation and sharing of observations.
Infinite plan achromatic objective lens ensures high-quality imaging over various magnifications, making the microscope versatile for different specimen examinations.
The digital microscope is illuminated by a 3W LED lamp that provides adjustable brightness for consistent and customizable lighting conditions.
Digital microscope combines cutting-edge optics, digital integration, and versatile accessories, making it a powerful tool for research, education and clinical applications.
