Non-contact Benchtop Spectrophotometer YR05480

Description

Description
The YR05480 non-contact desktop spectrophotometer is an innovative and highly precise solution for color measurement, designed for non-contact analysis of liquids, sauces, powders, and other delicate materials. This device utilizes a standard D/8 optical geometry, with diffuse illumination and 8° SCI reception, ensuring stable and accurate measurements each time. Equipped with a dual-array 256-pixel CMOS sensor, the YR05480 offers high optical resolution that enhances measurement speed and ensures consistent and reliable results. Its full-spectrum LED light source and concave grating technology ensure a complete spectral distribution within the visible range, minimizing maintenance costs and maximizing accuracy.

Technical parameters
Model YR05480
optical geometry D/8 (diffuse illumination, reception at 8°, SCI includes specular reflection light);
Complies with CIE standard No.15, GB/T 3978, GB 2893, GB/T 18833, ISO7724-1, ASTM E1164, DIN5033 Teil7, GB 2893, GB/T 18833
Features Non-contact test between the test probe and the tested sample, to achieve accurate non-contact color measurement of liquids, sauces, powders, etc. Mainly used for accurate color measurement and quality control of automated production lines; the measurement time can be adjusted from 0.2 to 1.5 seconds, and the software functions can be customized (additional customization function needs to be evaluated).
Light source Full-spectrum LED light source, UV light source
Spectrophotometric mode concave grid
Sensor 256-pixel dual-matrix CMOS image sensor
Wave range 400~700nm, 10nm output
Measured reflectance range 0-200%
Measuring aperture Φ20mm (Φ10mm can be customized)
Non-contact distance 3.0 mm (±0.2 mm)
Sample height Unlimited thickness, only test probes are used
Distance adjustment method Fixed height according to actual sample
Measuring mode Software customization function (additional customization function to be evaluated)
Locating camera location
Color space Laboratory CIE,XYZ,Yxy,LCh,LUV CIE,Musell,s-RGB,HunterLab,βxy,DIN Lab99
Color difference formula ΔE*ab,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),
ΔE*00,ΔE(Hunter),DINΔE99.

Other colorimetric index WI (ASTM E313, CIE/ISO, AATCC, Hunter),
YI(ASTM D1925，ASTM 313),
Index of metamerism MI,
Stain resistance, color fastness, strength, opacity, opacity
Observer angle 2°/10°
Illuminant D65,A,C,D50,D55,D75,F1,F2(CWF),F3,F4,F5,F6,
F7(DLF),F8,F9,F10(TPL5),F11(TL84),F12(TL83/ U30)

Data shown Spectrogram/values, sample chromaticity values, color difference/graphic values, color simulation, pass/fail result, display tolerance can be configured
Measuring time As fast as 0.2 seconds
Data storage Sample mode + Quality control mode 18,000
Continuous statistical mode 30,000, for a total of not more than 48,000
Repeatability In the optimal measurement mode (when the time of a single measurement is 1.5 seconds):
Spectral reflectance: within 0.1% of standard deviation:
Chromaticity value: ΔE*ab within 0.03 (after warming up and calibrating the instrument, measure the average value of the slate 30 times within 5 s).
Error between instruments Within ΔE*ab 0.2 (Average value measured from 12 mosaics of BCRA series Ⅱ).
Method of measurement Single measurement, average measurement (2~99 times)
Dimension 200*200*160mm (test probe)
Weight Approx. 3 kg (test probe only)
Energy AC 24V, power adapter power supply 3A
Illuminating life 5 years, more than 3 million times measurements
Monitor 7-inch TFT color LCD, capacitive touch screen
Data port USB, Bluetooth®5.0
Language Simplified Chinese, Traditional Chinese, English
Operating environment 0~40 ℃, 0~85 % RH (non-condensing), altitude: less than 2000 m
Storage environment -20~50℃, 0~85%RH (no condensation)
Standard accessory Power adaptor, manual, data cable, standard calibration plate, black calibration box
notes This model is especially suitable for optimized production lines, deep customization of functions will incur additional customization costs.
