Stormer Viscometer YR05857

Description

Description
The Stormer Viscometer YR05857 offers the perfect blend of cutting-edge touch screen technology and high precision in a sleek design, ensuring fast and accurate measurement of paint, coating, or ink viscosity. Featuring a vivid 5-inch color touch screen, it clearly displays various parameters and working conditions. This advanced viscometer is highly reliable, with robust features like strong anti-jamming performance, high measure accuracy, and excellent repeatability. It’s widely used in industries requiring the determination of KU values for paint, ink, or other substances, adhering to international standards like ASTM D562 and GB9296.

Features
Intuitive operation interface with data analysis capabilities
High precision with automatic computer calibration
Comprehensive display options including KU, G, CP, and temperature measurements
Real-time viscosity curve monitoring
Both serial and parallel connectivity interfaces
Robust data storage with access to multiple test results
Adjustable base level for accurate measurements
Optional accessories to enhance measurement accuracy

Technical Specifications
Model YR05857
Speed (r/min) 200±0.1
Measuring range 40.2KU – 141.0KU
32g – 1099g
27 – 5250CP
Measurement accuracy ±3%
Measurement reproducibility ±1.5%
Measuring container 1 pint
Save the measurement results 30 sets of data (including KU, G, cP, time, curves, etc.) can be saved
Viscograph Real time display viscosity curve
Power supply 110V / 60Hz or 220V / 50Hz
Dimension 350 * 350 * 450(mm)
