Syringe Pump YR05165

Description

Description
Syringe Pump YR05165 is designed to deliver precise and controlled infusion of fluids, ideal for medical and laboratory settings. Featuring a large 4.3-inch LCD screen, its full-color display ensures clear visibility under various lighting conditions. The pump operates on an advanced Linux-based system, guaranteeing safety and reliability. With multi-injection modes, remote control capabilities, and a comprehensive alarm system, this syringe pump is tailored for convenience and efficiency, saving time for medical professionals. The model can accommodate different syringe sizes and offers a high degree of accuracy, making it a versatile tool in any clinical environment.

Features
Large 4.3-inch LCD full-color display.
Operates efficiently under different lighting conditions.
Displays time, battery status, and several other operational indicators simultaneously.
Remote control for easy operation.
Based on a secure Linux system.
Multiple modes: V mode, T mode, and body weight mode.
Comprehensive alarm system for safety.

Technical Specifications
Model YR05165
Rate range 50ml syringe: 0.1~1800ml/h (0.1~999.9ml/h step:0.1ml/h)
30ml syringe: 0.1~900ml/h (1000~1800ml/h step: 0.1ml/h)
20ml syringe: 0.1~600ml/h
10ml syringe: 0.1~300ml/h
5ml syringe: 0.1~150ml/h
Volume Limit 0.1~1999.9ml (step: 0.1ml)
Accumulated volume 9999.9ml (step: 0.1ml)
Accuracy Within ± 2%
KVO Rate: 0.1~5ml/h (adjustable, step:0.1ml/h)
Fuse F1AL/250V(“F” indicate fast, low breaking, capacity) 2 pcs (installed inside pump)
Power Supply 110~220V, 50Hz, Built-in rechargeable battery, 11.1V, capacity≥2000mAh;
After charging 10 hours, it can work at 5ml/h (GB9706.27 average rate) about 4 hours.
Purge Rate 50ml syringe: 1800ml/h (Bolus rate: 1200ml/h)
30ml syringe: 900ml/h (Bolus rate: 600ml/h)
20ml syringe: 600ml/h (Bolus rate: 400ml/h)
10ml syringe: 300ml/h (Bolus rate: 200ml/h)
5ml syringe: 150ml/h (Bolus rate: 100ml/h)
Alarm Liquid volume nearly alarm, Liquid injection
Finish Alarm, Doses injection finished alarm, occlusion alarm, syringe off alarm, syringe non-interlaced correctly alarm, low
battery, low battery alarm.
Power off alarms.
Occlusion
Three levels for Occlusion: high, Middle, Low
Working Surrounding Temperature: +5~+40°C
Humidity: 20%~ 90%
Storage surrounding
Temperature: -30°C ~ +50°C
Humidity: ≤ 95%
Atmosphere Pressure 860hPa ~ 1060hPa
Safe Class
I type CF devices, Internal Battery, Intermittent
Load continues working
Size: 282mm(L) * 210mm(W) * 148mm(H)
Weight: 2.2kgs
Accessories Pump, Remote Controller, Power line, User manual, Guarantee card, Certificate
