The YR06075 – YR06076 Automatic Chemistry Analyzer represents the forefront of technology for laboratories requiring high performance and precise results in chemical analysis. With the capability to perform up to 560 tests per hour, these models are ideal for high-demand work environments. Their inverted diffraction network system, covering 12 wavelengths, ensures complete spectral coverage, providing precise and reliable measurements. Additionally, they feature an automatic washing system with 10 steps for the YR06075 model and 8 steps for the YR06076, minimizing carryover and guaranteeing the purity of results. The optional ISE modules (K, Na, Cl) and the built-in barcode scanner further facilitate efficiency and integration into the laboratory workflow.
Advantages:
High testing capacity: Up to 560 tests per hour, maximizing operational efficiency.
Spectral versatility: Coverage of 12 wavelengths allows for a wide range of analyses.
Resource efficiency: Low reagent and consumable consumption, reducing operating costs.
Technological integration: ISE module options and barcode scanner optimize workflow.
Disadvantages:
High initial cost: The investment may be significant for some laboratories, although justified by the equipment’s capabilities.
Dependence on energy: Requires a stable power source for continuous operation.
Technical Specifications
Model YR06075 YR06076
tests per hour 560/h 560/800 /h
steps wash system 10 8
Power supply: 100·240 VAC 50/60 Hz, 1500w
Temperature: 100C、300C
Humidity: 40%~85%
Water consumption: s20 Uhour
Dimension: 1150mm(L)0726.5mm(W)01150mm(H)
Light Source: Halogen tungsten lamp
Photometer: Grating photometry
Wavelengths: 340nm,405nm, 450nm, 505nm, 540nm, 570nm, 600nm, 635nm,670nm,700nm,760nm,795nm
Absorption range: 0~2.500Abs
Resolution: 0.0001 Abs
