Homogenizer, HMG-25, HMG-25D

Description

Application
It is a precision-engineered system designed for sample homogenization and emulsification. Compatible with multiple interchangeable work heads of varying specifications, it enables rapid sample dispersion, homogenization, emulsification, suspension, and mixing. It has been used in different fields of biological tissue processing (animal/plant cell disruption), pharmaceutical formulation, cosmetic emulsion, food technology, chemical synthesis.

Features
Interchangeable work heads (multiple specifications) for 0.2~10,000mL processing capacity, adaptable to diverse sample requirements.
Compact ergonomic design, delivering 27m/s linear velocity for precision homogenization.
Integrated vertical adjustment system with dual-axis support rod and bifurcated clamp ensures safety-critical operation.
Stepless speed control, up to 30,000 rpm with smooth acceleration control, offers 6 preset speed profiles. (HMG-25)
Continuously adjustable speed from 4,000 to 26,000 rpm, with programmable timer (0~999 min) enabling automatic shutdown upon completion.(HMG-25D)
Optional thermocouple probe provides real-time sample temperature monitoring; auto-stop at preset threshold prevents thermal degradation and ensures experimental safety.(HMG-25D)

Specification
Model HMG-25 HMG-25D
Type Basic Digital
Speed Range 7500~30000rpm 4000~26000rpm
Speed Range (H2O) 7500~26000rpm 4000~21000rpm
Speed Accuracy No data ±100rpm
Speed Control Gear adjustment Knob adjustment
Capacity 0.2~10000ml (Optional) 0.2~10000ml (Optional)
Time Display No Data LCD
Standard Configuration Machine+working head+stand Machine+working head+stand
Standard Working Head 25G 25G
Electricity 200-240V (optional 110V), 50-60Hz 200-240 (optional 110V), 50-60Hz
Motor Type DC Brushless motor DC Brushless motor
External Dimension 410*φ90mm 365*φ90mm
Net Weight 2.6kg 2.5kg
Package Dimension 803*400*140mm 810*410*150mm
Set Gross Weight 8kg 13kg
