Silicone Oil Heating Lyophilizer YR05985-1 – YR05985-2

Description

Description
The Silicone Oil Heating Lyophilizer YR05985-1 – YR05985-2 is a state-of-the-art vacuum freeze dryer that revolutionizes the drying process across various fields, including medicine, pharmaceuticals, biological research, chemicals, and food industries. This innovative device ensures that lyophilized articles retain their original biochemical properties after rehydration, making them easy to store long-term. With patented technology, the YR05985-1 and YR05985-2 models automate the once cumbersome process of drying and sublimation. Featuring shelf heating and programmable functions, these models offer the ability to observe and record freeze-drying curves to ensure optimal results.

Features
Patented square warehouse design for in-situ vacuum freeze-drying, ensuring easy operation and excellent drying results.
ACRYLIC drying chamber door for transparency and observability during the lyophilization process.
Safety diaphragm valve with inert gas connectivity, prolonging material shelf life post-drying.
Special gas guiding technology and cold trap with strong ice trapping capability.
Dual-machine cascade refrigeration from internationally renowned brands, emphasizing energy efficiency and low noise.
High precision temperature control with patented separator technology for uniform drying.

Technical Specifications
Model YR05985-1 YR05985-2
Freeze-drying area 0.7m2 1.04m2
Material plate size 475 × 355mm 475 × 355mm
Number of material trays 4 6
Shelf size 480 × 360mm 480 × 360mm
Number of shelves 4+1 floors 6+1 floor
Shelf spacing 50mm 70mm
Shelf temperature range -55 ° C ~ +70 ° C -55 ° C ~ +70 ° C
Shelf temperature difference ±1 °C (balanced) ±1 °C (balanced)
Cold trap temperature ≤ -75 ° C (no load) ≤ -75 ° C (no load)
Water catching capacity ≥10KG/24h ≥15KG/24h
Pumping rate 8L/S 15L/S
Ultimate vacuum ≤5pa (no load) ≤5pa (no load)
Installed power 5500w 6500w
Host weight 600kg 700kg
Mainframe dimensions 1000×785×1420mm 1170×830×1665mm
Cooling method air cooling air cooling
Plate loading material 7L (material thickness 10mm) 10L (material thickness 10mm)
